Quick detail:
1,Capacity:100kg/h-1ton/h
2,Certification:CE,SGS,ISO ect.
3,After-sales service:Engineer on-site service
4,Warranty:1 year
5,Brand: motor Siemens, inverter Delta
Macaroni pasta machine description:
Full automatic pasta macaroni production line adopts semolina flour as the main raw material, it could be used to produce various shapes of macaroni through extrusion, curing and mold forming. Our company adopts continuous vacuum pump with advanced technology and stable performance to produce pasta without bubbles with good taste ,so it becomes the preferred equipment for manufacturers.
The pasta food machine is characterized by unique technique, rational configuration, high automation and stable performance. It is the good equipment for macaroni factory using.
The screws of the pasta food making machine are made by ally steel and special craft, the screw life is longer, uses building block system structure, may combine willfully.
The forced lubrication system of pasta food making machine, by guaranteed equipment transmission longer life.
Macaroni pasta production line:
Production video:
Final Product:
Raw Materials:
adopts potato starch, corn starch, cassava starch, wheat flour, corn flour etc. as raw materials
Features of macaroni pasta machine line:
1. Swiss Technology,made in China;
2. PLC touch screen for Centralized ,accurate,convenient control
3. Fully automatic control system for heating and circulated cooling accurately
4. Direct transmission of motor and distribution box reduces energy loss.
5. Imported bearing group with higher bearing capacity
6. Equip with water injecting device on barrel to meet require of various raw material and quality.
7. High-speed tool steel with hardness HRC≥62 to ensure a longer service life.
8. Modular combination of screws at will to meet require of different raw material.
9. All barrels inlaid alloy sleeve, easy to replace and extend the life span of screw. All barrels inlaid cooling water through, spread around alloy sleeve, and can accurate constant temperature required
10. All screw sleeves is kneading, ensure that not accumulate material. The screw is installed by blocks, and can be replaced optionally ratio to achieve requirements for product. Screw sleeve is installed by spline, and it is convenient and efficient. Quality of screw sleeve according to different prices is divided into: Cr12MoV, 38CrMoAl, W6Mo5Cr4V2.
11. Applied to make all kinds of shapes like screw, pipe, shell etc.
Extruder model:
(The table can be dragged left and right to view)
Model | Installed Power | Power Consumption | Output | Size |
SSE100 | 65kw | 49kw | 100-120kg/h | 26*4*3m |
DSE75 | 131kw | 98kw | 250-350kg/h | 40*5*3.5m |
Flow chart:
Mixing—Screw conveyor—extruder—cooling machine—cutter—dryer—Cooling machine—Packing machine
Single & Twin screw extruder:
(The table can be dragged left and right to view)
![]() | |
Name | Single & Twin screw extruder |
Capacity | 100-150kg/h,250-350kg/h |
Power | 30kw,55kw |
Usage | To extrude the raw materials and make them to the required shape and size of the pasta macaroni by mould |
Advantage | 1,Screw: Material is 12CrMoV combined segmented screw New reinforced high-torque housing, gear material is 20CrNiMoA, 6-level gear accuracy, carburizing and quenching, HRC58 ~ 62, Japan NSK, IKO bearing, including condenser, filter. 2,Heating: No.45 shell of equipment barrel, with cooling water channel, C-type bimetal alloy bushing, alloy layer HRC58 ~ 62, heating, high thermal efficiency, reliable performance 3,Intelligent and fast PLC operation panel, real-time data feedback External water circulation intelligent temperature control system to maintain product production temperature and prevent swelling |
Dryer:
![]() | |
Name | Dryer |
Type | electrical, steam, gas fired, diesel fired heating type etc. |
Model | KX-3-5, KX-5-5, KX-5-8, KX-5-10, KX-7-5, KX-7-8, KX-7-10…. |
Capacity | 100kg/h to 10 ton/h |
Usage | the expanded food go through the "s" passage, to be dried to increase the self life. |
Advantage | 1. The oven has the compact structure, small occupying, large drying area, small surface area, slight radiating heat and high thermal efficiency. 2. The belt and the heat preservation use the stainless steel; it is suitable for food industry. 3. The running speed of belt net can be controlled (frequency) 4. The temperature can be controlled willfully and designed according to the need. 5. Grease nipples at the edges of the dryer to lubricate gears and bearings |
Now
PLC touch screen control
Before
The panel control
Control box
Now
the material 12CrMoV,38CrMoAl, including Integral screw,Sem assembled screw ,fully assembled screw
Before
Not a combination screw, a whole screw.
Screw
Now
the barrel with wear bushing extend the life of the screw,the life is more than 2 year.
Before
no wear bushing,the life is about 1 year.
Barrel
Dingrun
Delta or Siemens(those are offices all over the world)
Other Extruder Companies
Poor quallity,without CE or CCC or ULC
Inverter
Dingrun
Whatever stepper or servo driving
system Bright uses,all with top quailityand CE&CCC%UCL &UL
Other Extruder Companies
Poor quallity,without CE or CCC or ULC
Motor
Dingrun
World top brand : Omron, Schneider, Detal .All electrical component,cabinet,assembling and wiring meets the standard of IEC and ANSI
Other Extruder Companies
Made in China or brand copy,wiring,assembling can not even meet standard of China.
Electrical part
Dingrun
High flexible shielding cable,working between -75℃ to 115℃,95%,shielding scope
Wire
Other Extruder Companies
Poor quality shielding cable, cannot work efficiently for signal shielding,easily broken after working for a while,burn the motor easily
Dingrun
World top brand:NSK,SKF,FAG,long life accessories smooth operation,low noise
Other Extruder Companies
Poor quallity,high noise,short lift,low Accuracy
Bearing
